FEATURES

• TWO MANUAL MODES:
  Fast rewind socket port & starboard, or an amazing 10,200 lbs., on second speed with only 35lbs. Exerted on a 10" winch handle using the kedging socket located on top of winch. Both manual modes are operated with a standard winch handle. Rope wildcat allows rapid rope retrieval and can be tailed, even under power.

• MOTOR DRIVE:
  Continuous duty linear power unit, no field winding to burn out. No external grounding required (unit cannot induce electrolysis). No overload protector required for motor. Reversing is optional without changing motors. 12v, 24v, 32v, 110/220 VAC, and hydraulic power are available.

• CONSTRUCTION:
  All stainless steel type 316L construction, sealed case lifetime lithium lubrication, mounted to built-in base plate. Complete with chain pipes & cast urethane deck seal.

• MOUNTING:
  Required deck space for mounting plate is L10" X W11.6"., bowsprit mounts L12" X W4". Mounts with (6) ½" bolts. Motor mounts under deck and requires only 2" hole. Optional backing plates are available from the factory.

• GYPSY & WILDCAT:
  Standard cast bronze chromed gypsy & stainless steel wildcat are field interchangeable, port to starboard. A double wildcat or a double gypsy are optional. 1/4" through 7/16" BBB, PC or System 40HT, others available on request.

• POWER CONSUMPTION:
  12v: free run=8amps/rated pull=80amps
  24v: free run=4amps/rated pull=40amps

• CAPACITIES:
  Continuous line pull at 12v - 32v 1000 lbs. @ 37 fpm
  Maximum, depends on available amperage & power supply.

• DIMENSIONS:
  Height: 8" (203.2 mm) Width : 14.5" (368.3 mm)
  Length: 9.5" (241.3mm) Weight: 89 lbs. (40.5 Kg)
  Depth: From the top of deck: 14.5" (368.3mm)
  Unit will accept up to 4.5" (114.3mm) deck thickness as standard, optional extension housings to 48".

FEATURES:

• MULTIPLE OPERATIONAL CAPABILITIES:
  Port and Starboard chain retrieval and payout can be independently operated, or can be simultaneously operated in opposite directions (paying out one while retrieving another) also allows rope wildcats to be operated either independent of chain operations, or in conjunction with chain operations.

• MANUAL BACK-UP:
  Fast rewind socket port and starboard, or an amazing 10,200 lbs. On 2nd speed, with only 35 lbs. Exerted on a 10" winch handle, in kedging socket located on top of winch. Both manual modes are used in conjunction with a standard winch handle. Rope wildcat allows rapid rope retrieval and can be tailed, even under power.

• MOTOR DRIVE:
  Continuous duty linear power unit (no field windings to burn out). No external grounding required (unit cannot induce electrolysis). No overload protector required for motor. Reversing is optional without changing the motor. 12v, 24v, 32v, 110/220 VAC, and Hydraulic power are available.

• CONSTRUCTION:
  All stainless steel type 316L construction, sealed case lifetime lithium lubrication, mounted to built-in base plate. Comes with chain pipes & cast urethane deck seal.

• MOUNTING:
  Required deck space for mounting plate is L10" X W11.6", bowsprit mounts L12" X W4". Mounts with (6) ½" bolts. Motor mounts under deck and requires only 2" hole. Optional backing plates are available from the factory.

• GYPSY & WILDCAT:
  Standard cast bronze chromed gypsy & stainless steel wildcat port and starboard. ¼" through 7/16" BBB, PC, or System 40 HT are standard, others available on request.

• POWER CONSUMPTION:
  12v: free run=8amps/rated pull=80amps
  24v: free run=4amps/rated pull=40amps

• CAPACITIES:
  Continuous line pull at 12v - 32v 1000 lbs. @ 37 fpm.
  Maximum, depends on available amperage & power supply.

• DIMENSIONS
  Height: 8" (203.2mm)
  Length: 9.5" (241.3mm)
  Width: 24" (609.60mm)
  Weight 110 lbs. (50.00 Kg)
  Depth: From top of deck: 14.5" (368.3mm). Unit will accept up to 4.5" (114.3mm) deck thickness as standard. Optional extension housings to 48".
